Plots: Cassini Magnetospheric Studies

CAPS ELS Anodes 5 and 7 with MAG Data

The magnetometer data is in the first panel with the ELS anode 5 and 7 data in the next two panels. The bottom panel has the data sorted by pitch angle.

Use this layout

CAPS Pitch Angle Distribution

Top panel is Cassini MAG data in CAPS reference frame. Bottom four panels are CAPS ELS Pitch Angle Distributions: 0-45, 45-90, 90-135, 135-180.

Use this layout

CAPS Temperature / Density

Top panel is the temperature and density moments from CAPS. Second panel is the MAG data in the CAPS reference frame. Third panel is CAPS Pitch Angle Distribution in 0-45 degrees, Bottom panel is the CAPS Pitch Angle Distribution in 135-180 degrees.

Use this layout

CAPS ELS Energy Spectra

This will compare the energy of the pitch angle distributions at 0-45 degrees to 135-180 degrees. Each energy spectra is summed over the interval.

Use this layout
